1. Quick Start - Page 15
TitanUniversal_Man_v8-0_TT.doc 05 August 2014
[Fixture Overlap] sets each fixture to fade in sequence (100%=all
together, 0%=fixture waits for previous one to complete).
[Attribute times] sets individual fade times for different attributes.
[Fixture order] changes sequence for shapes and Overlap. (Section
8.5, p155).
Cue Lists
Cues may be stored in a Cue List which allows a full show to be run
from a Go button. Chases can be included using Autoload. Cue lists
can run in tracking or non-tracking mode.
1.4 Programming palettes
Set up the attributes to be recorded. If attribute is the same for all
fixtures of one type (e.g. colour), only one fixture need be set up and
palette will be “shared”.
Press Record, Palette.
Use [Set Mask] to choose attributes to record/exclude.
Press a grey palette button to store, or press a button in one of the
Colours/Positions/Gobos windows. (Section
5.1.2, p88).
To recall palette, select fixtures, select recall mask using Attribute
Bank buttons, press palette button.
To set a legend, press [Set Legend] then the palette’s button. Press
[Picture] to draw a picture legend.
Quick Record
Press an unused button in one of the windows – the button turns red
with a +. Press again to save the palette. The mask is automatically
set to match the window (e.g. Positions window is masked for only
position attributes).
Busking with palettes
To fade palettes when busking a show, select fixtures, type fade time
on the keypad then recall the palette (you have to do this each time).
If no fixtures selected, palette will recall to all applicable fixtures.
To set fixture overlap, type 0-100 then press [Set Overlap], then
recall the palette.
To set a fade time for all palettes, press Palette then [Master Time].
(Section
5.5, p97). Faded palettes do not go into the programmer so
don’t use fades when programming.
1.5 DMX / network setup
The console can output up to 12 universes of DMX (called DMX Lines)
which may be routed to the 4 XLR sockets or over Ethernet. The Pro
versions of Pearl Expert and Tiger Touch can output 16 Universes.
The Titan One dongle is limited to a single universe. By connecting
further DMX processing nodes to the network using TitanNet, you can
control up to 64 universes.
Multiple consoles can be linked by Ethernet to provide a multi-user
system, or to provide tracking backup (Section
10.6,p187).
