4. Controlling dimmers and fixtures
When you are programming a show, and sometimes when you are
running a show, you need to manually control the fixtures and
dimmers to set the intensity, position, colour, etc. To do this you first
select the fixtures you want to change using the select buttons, then
you set the attributes of those fixtures using the Wheels and Attribute
buttons.
You can also set fade/timing information for each attribute of each
fixture which is treated as an additional attribute of the fixture.
4.1 Using the select buttons and wheels
4.1.1 Selecting fixtures and dimmers for control
To select the fixtures or dimmer channels that you want to control,
you use the Fixture Select buttons to select the fixtures into the
Editor. You can select fixtures or dimmers individually, or several at
once.
1> Press the Select buttons for the fixtures you want. The select
button will light up pale blue for selected fixtures or on the
preset playback faders the select button will light up (they are
also shown in light blue on the HUD).
2> To select a range of fixtures, slide your finger across the touch
buttons to draw a selection box.
Here are some other things to know:
• Press Locate (at the bottom right of the console) to light up the
selected fixtures in open white and move them to a central
position. See the next section for more Locate options.
• You can deselect a fixture by pressing the select button again.
• In the system display area of the touch screen, the console will
show you which fixtures are currently selected.
• Press Clear (right of numeric keys) to deselect all fixtures and
remove all changes from the programmer. See the next section
for more Clear options.
Scroll slider
