Description
18 EN 03|2022
Filter settings
Under Filter settings, the parameter for the
filter cycle are defined. Status, duration and
pump speed can be set. The status is either
“On”
(√) or “Off”. The filter duration is set in
hours with a maximum of 24 hours. The
speed is specified in levels with 3 various
levels to choose from (n1 – n3).
Settings relay z1-z2 and z7-z8
One of the following controls/messages can
be set in the Settings relay z1-z2 and relay
z7-z8 menu:
• Off: without function
• Z: Release (Individual selection for
individual positions)
• Ξ: Heating control
• ‘‘: Cooling
• ☼: Solar control
• E: Error message
• T: Timer
The appropriate parameters and limits must
be entered accordingly.
Factory setting:
Z1-z2: Release
The parameters (delay time, safety time) of
the level control can be changed for the
output contact in the Settings relay 11-14
