Function Value Default Actions
8 - 15 Activate default macro (full screen) (If held for 1 second)
16 - 23 Activate macro 2 (If held for 1 second)
9
24 - 31 Activate macro 3 (If held for 1 second)
9
32 - 39 Activate macro 4 (If held for 1 second)
9
40 - 47 Activate macro 5 (If held for 1 second)
9
48 - 55 Activate macro 6 (If held for 1 second)
9
56 - 63 Activate macro 7 (If held for 1 second)
9
64 - 71 Activate macro 8 (If held for 1 second)
9
72 - 79 Activate macro 9 (If held for 1 second)
9
80 - 87 Activate macro 10 (If held for 1 second)
9
88 - 95 Select input 1: HDMI Input (If held for 1 second)
96 - 103 Select input 2: DisplayPort Input (If held for 1 second)
104 - 111 Select input 3: SDI Input A (If held for 1 second)
112 - 119 Select input 4: SDI Input B (If held for 1 second)
120 -
127
Select input 5: HDBaseT Input 1 (if held for 1 second)
128 -
135
Select input 6: Dual DisplayPort input (if held for 1 second)
136 -
143
Select input 7: DVI (if held for 1 second)
144 -
151
Select input 8: Dual DVI (if held for 1 second)
152 -
159
Reserved for future functionality
160 -
167
Reserved for future functionality
168 -
175
Reserved for future functionality
176 -
183
Reserved for future functionality
184 -
255
Reserved for future functionality
5 Focus (MSB) 0 - 255 128 Set coarse lens focus adjustment
10
6 Focus (LSB) 0 - 255 128 Set fine lens focus adjustment
10
7 Zoom (MSB) 0 - 255 128 Set coarse lens zoom adjustment
10
8 Zoom (LSB) 0 - 255 128 Set fine lens zoom adjustment
10
9 Lens shift vertical
(MSB)
0 - 255 128 Set coarse lens shift in vertical direction
10 Lens shift vertical
(LSB)
0 - 255 128 Set fine lens shift in vertical direction
11 Lens shift horizontal
(MSB)
0 - 255 128 Set coarse lens shift in horizontal direction
12 Lens shift horizontal
(LSB)
0 - 255 128 Set fine lens shift in horizontal direction
13 Light Source
Power
11
0 - 3 0 Set light source to 100%
4 - 7 Set light source to 95%
8 - 11 Set light source to 90%
12 - 15 Set light source to 85%
16 - 20 Set light source to 80%
DMX chart
10. Only when lens has been calibrated
11. If the Light Source is forced to a output below its minimum value, it will remain at its minimum output value
