Barco SP2K-S

R5913197 /02 SP2K-S52
1
1
Image 4–14
2. Change the orientation of the air outlet (reference 2).
2
Image 4–15
3. Tighten the eight TX M4 screws (reference 1) to secure the part with the air outlet (reference 2).
Physical installation projector
