Image 4–12
Bigger bending feature should be put between the top of the projector handle and the projector itself.
Image 4–13
5. Follow the next steps if you want modify the air ring direction:
1. Remove the eight TX M4 screws (reference 1) holding the part with the air outlet. Use a Torx
screwdriver T20.
Physical installation projector
