Basler acA2040-55 User Manual

Features AW00123409000
244 Basler ace USB 3.0
3
1
0
P
1
P
Use Case: Asynchronous cycling through sequencer sets, according to path 1,
cycling interrupted by asynchronous reset according to path 0
Settings: Acquisition Mode = Continuous
Trigger Mode for the frame start trigger = On
Trigger Activation for the frame start trigger: Rising Edge
Frame start triggers applied externally via Line 1
Asynchronous trigger source for sequencer set advance:
Software Signal 3
Asynchronous trigger source for reset of sequencer set advance:
Software Signal 1
2 0 1 00-1
3
1
3 3
31
3
P
P
3
0
1
0
0 0
0
2 0 1
Time
Software Signal 1
Trigger Source,
Path 0
= delay between sending the advance command and it becoming effective
= delay between sending the reset command and it becoming effective
= trigger signal generated externally
= Software Signal trigger source (Software Signal 1) for asynchronous reset of sequencer set advance
Sequencer
Mode Set to
On
Software Signal 3
Trigger Source,
Path 1
Frame Start
Trigger Signal
Sequencer
Mode Set to
Off
= Software Signal trigger source (Software Signal 3) for asynchronous sequencer set advance
= frame exposure and readout
= frame transmission
= camera is waiting for a frame start trigger
Fig. 91: Use Case 3 - Asynchronous Cycling Through Sequencer Sets According to Path 1, One Reset
= camera loads a sequencer set into the active set making it the current set
= current sequencer set that is used for image acquisition; sequencer set was just loaded
= current sequencer set that is used for image acquisition; already present in the active set
= current sequencer set that is in the active set immediately before the sequencer feature is enabled
= current sequencer set; was in the active set before it was overwritten by sequencer set -1
