EventSelector VCXG.2 VCXG.2XC VCXG.2.I VCXU.2
GigEVisionHeartbeatTime-
Out
■ ■ ■ □
Line0..3 FallingEdge ■ ■ ■ (0..7) ■
Line0..3 RisingEdge ■ ■ ■ (0..7) ■
TransferBufferFull ■ ■ ■ ■
TransferBufferReady ■ ■ ■ ■
TriggerOverlapped ■ ■ ■ ■
TriggerReady ■ ■ ■ ■
TriggerSkipped ■ ■ ■ ■
11.11.3 LostEventCounter
Counts lost Events.
Name LostEventCounter
Category EventControl
Interface IInteger
Access Read only
Unit -
Values 0 ... 9223372036854775807 (Increment: 1)
11.12 Category: ImageFormatControl
This chapter describes how to influence and determine the image format control features.
General Information - Region of Interest (OffsetX / OffsetY / Width / Height)
Function Region of Interest (ROI) is used to predefine a so-called Region of Interest. This ROI
is a defined range of sensor pixels. At image acquisition, only this pixel-specific information is
transferred to PC. Not all of the lines on the sensor are read out, which therefore decreases the
readout time (treadout). This allows for increased frame rates.
This function is used if only a particular region in the field of view is of interest. Further it will re-
duce resolution.
The ROI is specified by four values:
n
OffsetX - x-coordinate of the first relevant pixel
n
OffsetY - y-coordinate of the first relevant pixel
n
Width - horizontal size of the ROI
n
Height - vertical size of the ROI
