Example: Triggering multiple cameras
The following illustration shows three cameras with synchronous trigger by software application.
11.2.1 ActionDeviceKey
Provides the device key that allows the device to check the validity of action commands. The
device internal assertion of an action signal is only authorized if the ActionDeviceKey and the
action device key value in the protocol message are equal.
Name ActionDeviceKey
Category ActionControl
Interface IInteger
Access Write only
Unit HexNumber
Values 0 - 4294967295 (Increment: 1)
11.2.2 ActionGroupKey
Provides the key that the device will use to validate the action on reception of the action proto-
col message.
Name ActionGroupKey
Category ActionControl
Interface IInteger
Access Read / Write
Unit HexNumber
Values 0 - 4294967295 (Increment: 1)
