Baumer VCXG.2 Series - Filter Glass Color Cameras; Cover Glasses Tubes; Spectral Sensitivity

6 | Optical specification Baumer
50 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
6.3.2 Filter glass color cameras
0%
1
0%
20%
30%
40%
50%
60%
70%
80%
90%
100%
300 400 500 600 700 800 900 1000 1100 1200
Transmission
Wavelength in nm
Filter glass of color cameras
Filter glass color cameras
6.3.3 Cover glasses Tubes
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
300 400 500 600 700 800 900 1000 1100 1200
Transmission
Wavelength in nm
Cover Glass Tube: Acryl
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
300 400 500 600 700 800 900 1000 1100 1200
Transmission
Wavelength in nm
Cover Glass Tube: restistant laminated safety cover glass
Cover Glass Tube: Acrylic Cover glass tube: resistant laminated safety
glass
6.3.4 Spectral sensitivity
The following diagrams show the spectral sensitivity characteristics for this camera series. The
characteristic curves for the sensors do not take the characteristics of lenses and light sources
without filters into consideration.
The values refer to the related data sheets.
Cameras
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
Sony
®
IMX 273 mono
400 500 600 700
800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
Sony
®
IMX 273 mono
Spectral sensitivity VCXG.2-15M.I
(Sony
®
IMX273)
Spectral sensitivity VCXG.2-15C.I
(Sony
®
IMX273)
