3 | Description Baumer
16 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
3.1.4 Dimensional drawing
29
29
20
20
4,45
7,2
8,7
20
3
28,7
20
22
40
C-mount
6,6 ±0,3548,98,9
3
8 x M3 x 4
2 x M3 x 4
ø
Ill.1: Dimensional drawing - VCXG
