6.2.2 Spectral sensitivity
The following diagrams show the spectral sensitivity characteristics for this camera series. The
characteristic curves for the sensors do not take the characteristics of lenses and light sources
without filters into consideration.
The values refer to the related data sheets.
Cameras
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
Sony
®
IMX 264 mono
Spectral sensitivity VCXG.2-51M.XC
(Sony
®
IMX264)
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
Sony
®
IMX 540 mono
Spectral sensitivity VCXG.2-241M.XC
(Sony
®
IMX540)
