Baumer VCXG.2 Series - Page 39

Baumer Installation | 5
V1.2 | VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 Operating Manual 39
Tube
Art. No.: 11185370 (Cover Glass: Acryl)
Art. No.: 11195425 (Cover Glass: restistant laminated safety cover glass)
A
A
A-A
49,5
46
M47 x 0,75
38,1
40,5
4
44
Ø
Ø
Ø
M 47
Art. No.: 11185374 (Cover Glass: Acryl)
Art. No.: 11195426 (Cover Glass: restistant laminated safety cover glass)
M 62
A
A
A-A
Ø
5
6
Ø 16
M62 x 0,75
50,2Ø
54,5
4
58
A-A
95
91
92M x 0,75
83.1
66.5
5
70
A
A
M 92
Art. No.:
11704312 / Cover glass: PMMA (Acryl)
Ø
Ø
Ø
Tube: inner dimensions
M 47
44
38,2Ø
Ø 64
35
M 62
Ø 16
58
49
50,2Ø
