6 | Optical specification Baumer
44 Operating Manual VCXG.2 / VCXG.2.XC / VCXG.2.I / VCXU.2 | V1.2
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
Sony
®
IMX 548 mono
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
Sony
®
IMX 548 color
Spectral sensitivity VCXG.2-57M
(Sony
®
IMX548)
Spectral sensitivity VCXG.2-57C
(Sony
®
IMX548)
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
W
ave Length [nm]
Relative Response
Sony
®
IMX 178 mono
400 450 500 550 600 650 700
0
0.2
0.4
0.6
0.8
1.0
Sony
®
IMX 178 color
Relative Response
Wave Length [nm]
Spectral sensitivity VCXG.2-65M.R
(Sony
®
IMX178)
Spectral sensitivity VCXG.2-65C.R
(Sony
®
IMX178)
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
Sony
®
IMX 546 mono
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
Sony
®
IMX 546 color
Spectral sensitivity VCXG.2-82M
(Sony
®
IMX546)
Spectral sensitivity VCXG.2-82C
(Sony
®
IMX546)
