RX680R User’s Manual
12
1 x 2 Audio Connector, Green color for line-out, Pink color for Mic-In
Internal I/O Connector
Internal I/O
4 x SATA III Vertical Connectors (Red)
5 x RS-232 Headers with Voltage Selection
1 x RS-232/422/485 Headers with Voltage Selection
1 x PS/2 Header
1 x LPT Header
4 x USB 2.0 Headers with Shroud (8 Ports on Header)
1 x USB 3.2 Gen 1x1 Header with Shroud (2 Ports on Header)
1 x LVDS Header
1 x Backlight Locking Type Header
1 x SPI Header
1 x I
2
C Header
1 x SMBUS Header
1 x Front Audio Header with Shroud
1 x Amplifier Locking Type Header
1 x Front Panel Headers with
Shroud
1 x 8 bits GPIO Header with Shroud
1 x 4 Pin CPU Fan Header (4 Pin PWM)
2 x 4 Pin Chassis Fan Header (4 Pin PWM)
2 x LAN Status LED Headers
1 x Horizontal Socket Type CMOS Battery Holder
1 x Chassis Intrusion Locking Type Header
1 x eSPI Header
1 x Std. 24 pin ATX Connector
1 x 8 pin ATX 12 Connector
1 x AT/ATX Mode Jumper
Mechanical & Environmental
Operating Temperature
0 C to 60 C
Operating Humidity
5% to 90% non-condensing
Size (LxW)
9.6” (L) x 9.6” (W)
