2.3.1.1 Memory Configuration
Main
Advanced
Chipset
Boot
Security
Save & Exit
Memory Configuration
Item help
Memory RC Version
0.0.3.128
→←: Select Screen
Memory Frequency
4400 Mhz
↑↓: Select Item
(tCL-tRCD-tRP-tRAS)
36-36-36-71
Enter: Select
MC 0 CH 0 DIMM 0
Not Populated /
Disabled
+/- : Change Opt
MC 0 CH 0 DIMM 1
Not Populated /
Disabled
F3: Optimized Defaults
MC 1 CH 0 DIMM 0
Not Populated /
Disabled
MC 1 CH 0 DIMM 1
Populated &
Enabled
Size
Number of Ranks
32768 MB (DDR5)
2
Manufacturer
Samsung
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
Field Name
Memory RC Version
Help
Memory Reference Code version
Comment
This field is not selectable. There is no help text associated with it.
Field Name
Memory Frequency
Help
Memory speed
Comment
This field is not selectable. There is no help text associated with it.
Field Name
tCL-tRCD-tRP-tRAS
Help
Memory detail timings
Comment
This field is not selectable. There is no help text associated with it.
Field Name
MC 0 CH 0 DIMM
Help
Memory size/ranks/manufacturer in the DIMM.
Comment
This field is not selectable. There is no help text associated with it.
