BCM RX680R - E Cnvi Configuration

RX680R User’s Manual
85
2.3.2.1.6 M.2 E CNVi Configuration
Main
Advanced
Chipset
Boot
Security
Save & Exit
CNVi CRF Present Yes
CNVi Configuration
Item help
CNVi Mode
[Auto Detection]
Wi-Fi Core
[Enabled]
→←: Select Screen
BT Core
[Enabled]
↑↓: Select Item
Enter: Select
+/- : Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
Field Name
CNVi CRF Present
Help
CNVi CRF Present
Comment
This field is not selectable. There is no help text associated with it.
Field Name
CNVi Mode
Default Value
[Auto Detection]
Possible Value
Disable Integrated / Auto Detection
Help
This option configures Connectivity. [Auto Detection] means that if Discrete solution is
discovered it will be enabled by default. Otherwise Integrated solution (CNVi) will be
enabled. And [Disable Integrated] is disables Integrated Solution.
NOTE: When CNVi is present, the GPIO pins that are used for radio interface cannot be
assigned to the other native function.
Field Name
Wi-Fi Core
Default Value
[Enabled]
Possible Value
Enabled / Disabled
Help
This is an option intended to Enable/Disable Wi-Fi Core in CNVi
Field Name
BT Core
Default Value
[Enabled]
Possible Value
Enabled / Disabled
Help
This is an option intended to Enable/Disable BT Core in CNVi
