2.3.1.3 VMD setup menu
Main
Advanced
Chipset
Security
Boot
Save & Exit
VMD Configuration
Item help
Enable VMD controller
[Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/- : Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
Field Name
Enabled VMD controller
Default Value
[Disabled]
Possible Value
Disabled / Enabled
Help
Enable/Disable to VMD controller
2.3.2 PCH-IO Configuration
Main
Advanced
Chipset
Security
Boot
Save & Exit
MEBx
PCH-IO Configuration
Item help
►PCI Express Configuration
↑↓: Select Item
►SATA Configuration
Enter: Select
►USB Configuration
+/- : Change Opt
►HD Audio Configuration
F1: General Help
F2: Previous Values
LVDS Board I225 LAN1 Controller
[Enabled]
F3: Optimized Defaults
LVDS Board I225 LAN2 Controller
[Enabled]
F4: Save & Reset
Wake On Lan from LAN Device
[Enabled]
ESC: Exit
DeepSx Power Policies
[Disabled]
State After G3
[S5 State]
GPIO Group Control
Chassis Intrusion
[Disabled]
[Disabled]
Version 2.21.1278. Copyright (C) 2021 AMI
