BCM RX680R - S5 RTC Wake Settings

RX680R User’s Manual
67
Field Name
Temperature 4
Default Value
By thermal fan profile.
Possible Value
By temperature.
Help
The value of temperature 4
Field Name
FD / RPM 1
Default Value
By thermal fan profile.
Possible Value
By Fan Duty.
Help
The value of Fan Duty/RPM 1 when temperature is T1
Field Name
FD / RPM 2
Default Value
By thermal fan profile.
Possible Value
By Fan Duty.
Help
The value of Fan Duty/RPM 2 when temperature is T2
Field Name
FD / RPM 3
Default Value
By thermal fan profile.
Possible Value
By Fan Duty.
Help
The value of Fan Duty/RPM 3 when temperature is T3
Field Name
FD / RPM 4
Default Value
By thermal fan profile.
Possible Value
By Fan Duty.
Help
The value of Fan Duty/RPM 4 when temperature is T4
2.2.7 S5 RTC Wake Settings
Main
Advanced
Chipset
Security
Boot
Save & Exit
MEBx
Item help
Wake system from S5
[Disabled]
→←: Select Screen
↑↓: Select Item
+/- : Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.21.1278. Copyright (C) 2021 AMI
Field Name
Wake system from S5
Default Value
[Disabled]
Possible Value
Disabled
Fixed Time
Dynamic Time
Help
Enable or disable System wake on alarm event. Select FixedTime, system will wake
on the hr::min::sec specified. Select DynamicTime , System will wake on the current
time + Increase minute(s).
