2.2.5.3 Serial Port 3 Configuration
Main
Advanced
Chipset
Security
Boot
Save & Exit
MEBx
Serial Port 3 Configuration
Item help
Serial Port
[Enabled]
→←: Select Screen
Device Settings
IO=3E8h; IRQ=7;
↑↓: Select Item
Enter: Select
Change Settings
[Auto]
+/- : Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.21.1278. Copyright (C) 2021 AMI
Field Name
Serial Port
Default Value
[Enabled]
Possible Value
Disabled
Enabled
Help
Enable or Disable Serial Port(COM)
Field Name
Device Settings
Default Value
Device Super IO COM3 Address and IRQ.
Comment
This field is not selectable. There is no help text associated with it.
Field Name
Change Settings
Default Value
[Auto]
Possible Value
Auto
IO=3E8h; IRQ7;
IO=3E8h; IRQ3,4,5,6,7,9,10,11,12;
IO=2E8h; IRQ3,4,5,6,7,9,10,11,12;
IO=220h; IRQ3,4,5,6,7,9,10,11,12;
IO=228h; IRQ3,4,5,6,7,9,10,11,12;
Help
Select an optimal settings for Super IO Device
