RX680R User’s Manual
18
1.2.4 Layout Content List
Slots & Sockets
Print Name
Function
Note
CPU1
LGA 1700 Socket
J50~J53
DDR5 UDIMM Slots
Dual channel (2DPC)
PCIE_X16_SLOT1
Gen 5 PCIe
x16 Physical Black (Slot1)
PCIE_X4_SLOT2
Gen 3 PCIe
x4 Open Ended (Slot 2)
PCIE_X16_SLOT4
Gen 4 PCIe
x4 (x16 Physical Yellow) (Slot 4)
PCIE_X16_SLOT3
Gen 4 PCIe
x4 (x16 Physical Yellow) (Slot 3)
M2M1
Gen 4 PCIe x4 + SATA III
M Key
M2M
Gen 3 PCIe x4 + SATA III
M Key
M2E
PCIe x 1 + USB 2.0 support
CNVi
E Key
Jumper
Print Name
Function
Note
PANEL_SEL1
LVDS Panel Power Select
2x3 header, pitch 2.54mm
BKLVOL1
LVDS Blacklight Control
1x3 header, pitch 2.00mm
AT1
AT/ATX Mode Select
1x3 header, pitch 2.54mm
CMOS1
Clear CMOS
1x3 header, pitch 2.00mm
J56,J45~J48,J25
COM1~COM6 Power Setting
2x3 header, pitch 2.54mm
Rear I/O Connectors
Print Name
Function
Note
DisplayPort
DisplayPort Connectors x4
USB3.2
USB 3.2 Type A Connectors x2
USBC
USB 3.2 Type C Connector x1
USB3.2+LAN
RJ45 Ethernet Connectors x2
2.5 Gigabit Ethernet
USB 3.2 Type A Connectors x4
AUDIO
Audio Phone Jack
Lin-out, Mic-in
