BCM RX680R - USB Configuration

RX680R User’s Manual
87
2.3.2.3 USB Configuration
Main
Advanced
Chipset
Boot
Security
Save & Exit
USB Configuration
Item help
xDCI Support
[Disabled]
→←: Select Screen
Rear IO USB3 Gen1 Power
[Enabled]
↑↓: Select Item
Rear IO LAN2 USB3 Gen2 Power
[Enabled]
Enter: Select
Rear IO LAN1 USB3 Gen2 Power
[Enabled]
+/- : Change Opt
Front IO USB3 Gen1 Header Power
[Enabled]
F1: General Help
Front IO USB2 Header 4 Power
[Enabled]
F2: Previous Values
Front IO USB2 Header 3 Power
[Enabled]
F3: Optimized Defaults
Front IO USB2 Header 2 Power
[Enabled]
F4: Save & Reset
Front IO USB2 Header 1 Power
[Enabled]
ESC: Exit
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
Field Name
xDCI Support
Value
[Disabled]
Possible Value
Disabled / Enabled
Help
Enable/Disable xDCI (USB OTG Device).
Field Name
Rear IO USB3 Gen1 Power
Value
[Enabled]
Possible Value
Disabled / Enabled
Help
Enable/Disable Upper/Lower USB ports of HDMI Rack.
Field Name
Rear IO LAN2 USB3 Gen2 Power
Value
[Enabled]
Possible Value
Disabled / Enabled
Help
Enable/Disable Upper/Lower USB ports of i211 RJ45 Rack.
Field Name
Rear IO LAN1 USB3 Gen2 Power
Value
[Enabled]
Possible Value
Disabled / Enabled
Help
Enable/Disable Upper/Lower USB ports of i219 RJ45 Rack.
Field Name
Front IO USB3 Gen1 Header Power
Value
[Enabled]
Possible Value
Disabled / Enabled
Help
Enable/Disable USB3 Gen1 ports of USB3 Header.
Field Name
Front IO USB2 Header 4 Power
Value
[Enabled]
Possible Value
Disabled / Enabled
Help
Enable/Disable USB ports of USB2 Header 4.
