RX680R User’s Manual
84
2.3.2.1.5 PCI Express X4 SLOT4
Main
Advanced
Chipset
Boot
Security
Save & Exit
Item help
PCI Express X4 SLOT4
[Enabled]
ASPM
[L1]
→←: Select Screen
L1 Substates
[L1.1 & L1.2]
↑↓: Select Item
PCI Speed
[Auto]
Enter: Select
+/- : Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
Field Name
PCI Express X4 SLOT4
Default Value
[Enabled]
Possible Value
Disabled / Enabled
Help
Control the PCI Express Root Port.
Field Name
ASPM
Default Value
[L1]
Possible Value
Disabled / L1 / Auto
Help
Set the ASPM Level:Force L0s - Force all links to L0s State AUTO - BIOS auto
configure DISABLE - Disables ASPM
Field Name
L1 Substates
Default Value
[Disabled]
Possible Value
Disabled / L1.1 / L1.1 & L1.2
Help
PCI Express L1 Substates settings.
Field Name
PCIe Speed
Default Value
[Auto]
Possible Value
Auto / Gen1 / Gen2 / Gen3
Help
Configure PCIe Speed
