BCM RX680R - PCI Express Configuration

RX680R User’s Manual
79
Field Name
Chassis Intrusion
Default Value
[Disabled]
Possible Value
Disabled
Enabled
Reset
Help
Configure Chassis Intrusion.
Field Name
PCH INTRD DET STATUS
Default Value
0
Possible Value
0
1
Help
Configure Chassis Intrusion.
2.3.2.1 PCI Express Configuration
Main
Advanced
Chipset
Boot
Security
Save & Exit
PCI Express Configuration
Item help
►PCI Express M.2 E
►PCI Express M.2 M
→←: Select Screen
►PCI Express X4 Open End
↑↓: Select Item
►PCI Express X4 SLOT3
Enter: Select
►PCI Express X4 SLOT4
+/- : Change Opt
►M.2 E CNVi Configuration
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
Field Name
PCI Express M.2 E
Help
PCI Express Root Port Settings
Comment
Press Enter when selected to go into the associated Sub-Menu.
Field Name
PCI Express M.2 M
Help
PCI Express Root Port Settings
Comment
Press Enter when selected to go into the associated Sub-Menu.
Field Name
PCI Express X4 Open End
Help
PCI Express Root Port Settings
Comment
Press Enter when selected to go into the associated Sub-Menu.
Field Name
PCI Express X4 SLOT3
Help
PCI Express Root Port Settings
Comment
Press Enter when selected to go into the associated Sub-Menu.
