RX680R User’s Manual
60
2.2.5.7 Parallel Port Configuration
Main
Advanced
Chipset
Security
Boot
Save & Exit
MEBx
Parallel Port Configuration
Item help
Serial Port
[Enabled]
→←: Select Screen
Device Settings
IO=278h; IRQ=5;
↑↓: Select Item
Enter: Select
Change Settings
[Auto]
+/- : Change Opt
Device Mode
[STD Printer Mode]
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.21.1278. Copyright (C) 2021 AMI
Field Name
Parallel Port
inDefault Value
[Enabled]
Possible Value
Disabled
Enabled
Help
Enable or Disable Parallel Port(LPT/LPTE)
Field Name
Device Settings
Default Value
Device Super IO Parallel Port Address and IRQ.
Comment
This field is not selectable. There is no help text associated with it.
Field Name
Change Settings
Default Value
[Auto]
Possible Value
Auto
IO=378h; IRQ=5;
IO=378h; IRQ5,6,7,9,10,11,12;
IO=278h; IRQ5,6,7,9,10,11,12;
IO=3BCh; IRQ5,6,7,9,10,11,12;
Help
Select an optimal settings for Super IO Device
Field Name
Device Mode
Default Value
[STD Printer Mode]
Possible Value
STD Printer Mode
SPP Mode
EPP-1.9 and SPP Mode
EPP-1.7 and SPP Mode
ECP Mode
ECP and EPP 1.9 Mode
ECP and EPP 1.7 Mode
Help
Change the Printer Port mode.
