RX680R User’s Manual
66
2.2.6.1.3 Rear Fan setting
Main
Advanced
Chipset
Security
Boot
Save & Exit
Item help
Rear Fan Setting
Rear Fan Mode
[SMART FAN IV]
Temperature 1
40
Temperature 2
50
Temperature 3
60
Temperature 4
70
FD/RPM 1
76
FD/RPM 2
127
FD/RPM 3
178
FD/RPM 4
229
→←: Select Screen
↑↓: Select Item
Enter: Select
+/- : Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
Version 2.21.1278. Copyright (C) 2021 AMI
Field Name
Rear Fan Mode
Default Value
[SMART FAN IV]
Possible Value
Manual mode
SMART FAN IV
Help
Fan control mode select
Field Name
Temperature 1
Default Value
By thermal fan profile.
Possible Value
By temperature.
Help
The value of temperature 1
Field Name
Temperature 2
Default Value
By thermal fan profile.
Possible Value
By temperature.
Help
The value of temperature 2
Field Name
Temperature 3
Default Value
By thermal fan profile.
Possible Value
By temperature.
Help
The value of temperature 3
