BCM RX680R - HDD Security

RX680R User’s Manual
90
Field Name
Secure Boot
Help
Secure Boot Configuration
Comment
Press Enter when selected to go into the associated Sub-Menu.
Field Name
HDD Security Configuration
Help
HDD Security Configuration for selected drive
Comment
Press Enter when selected to go into the associated Sub-Menu.
2.4.1 HDD Security
Main
Advanced
Chipset
Security
Boot
Save & Exit
HDD Password Description :
Item help
Allows Access to Set, Modify and Clear
Hard Disk User Password
and Master Password.
User Password is mandatory to Enable HDD Security.
If Master password is installed (optional),
it can also be used to unlock the HDD.
If the 'Set User Password' option is hidden,
do power cycle to enable the option again.
HDD PASSWORD
CONFIGURATION:
→←: Select Screen
Security Supported :
Yes
↑↓: Select Item
Security Enabled :
No
Enter: Select
Security Locked :
No
+/- : Change Opt
Security Frozen :
No
F1: General Help
HDD User Pwd Status :
NOT INSTALLED
F2: Previous Values
F3: Optimized Defaults
Set User Password
F4: Save & Reset
ESC: Exit
Version 2.21.1278. Copyright (C) 2021 AMI
Field Name
Set User Password
Help
Set HDD User Password. *** Advisable to Power Cycle System after Setting Hard Disk
Passwords ***.Discard or Save changes option in setup does not have any impact on HDD when
password is set or removed. If the 'Set HDD User Password' option is hidden, do power cycle to
enable the option again
