RX680R User’s Manual
68
2.2.8 AMI Graphic Output Protocol Policy
Main
Advanced
Chipset
Security
Boot
Save & Exit
Intel (R) Graphics Controller
Item help
Intel (R) GOP Driver [17.0.1073]
Output Select
[EDP1 + DP1[ACTIVE]]
→←: Select Screen
Output Panel Type
[Disabled]
↑↓: Select Item
Backlight Control
[PWM Normal]
Enter: Select
LCD Panel Type
[1920x1080 24bit Dual
Channel]
+/- : Change Opt
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
Field Name
Output Select
Default Value
By attached device.
Possible Value
eDP / DP1 / DP2 / DP3 / DP4
Help
Output Interface
Field Name
Output Panel Type
Default Value
[Disabled]
Possible Value
eDP
LVDS
Disabled
Help
Select Output Panel Type
Field Name
Backlight Control
Default Value
[PWM Normal]
Possible Value
PWM Inverted
PWM Normal
Help
Back Light Control Setting
Field Name
LVDS Panel Type
Default Value
[1920x1080 24bit Dual Channel]
Possible Value
800x600 18bit Single Channel
1024x768 18bit Single Channel
1024x768 24bit Single Channel
1280x768 18bit Single Channel
1280x800 24bit Single Channel
1280x960 18bit Single Channel
1280x1024 24bit Dual Channel
1366x768 18bit Single Channel
1366x768 24bit Single Channel
1440x900 24bit Dual Channel
1440x1050 24bit Dual Channel
1600x900 24bit Dual Channel
