RX680R User’s Manual
19
Internal I/O Connectors
Print Name
Function
Note
CPU_FAN1
CPU FAN Connector
WAFER 1x4, 2.54mm
SYS_FAN1
Chassis Fan Connector
WAFER 1x4, 2.54mm
SYS_FAN2
Chassis Fan Connector
WAFER 1x4, 2.54mm
FIO_PANEL1
Front Panel Connector
BOX header 2x5P, 2.54mm
ATX24P_1
ATX Power Connector
PWR Conn 2x12P
ATX12V
12V ATX Power Connector
PWR Conn 2x4P
COM1~COM6
Serial Port Connectors
WAFER 2x5P, 2.00mm
SATA1~4
SATA Connectors
Male Connectors (RED)
USB2_HR1~4
Front USB 2.0 Headers
BOX header 2x5P, 2.54mm
USB3_HR1
Front USB 3.2 Header
BOX header 2x10P, 2.00mm
FIO_AUD1
Front Audio Connector
BOX header 2x5P, 2.54mm
SPK1
Amplifier Connector
WAFER 1x4P, 2.00mm
LVDS1
LVDS signals connector
Con. 2x20P, 1.25mm
INTRUD1
Chassis Intrusion Header
WAFER 1x2P, 2.54mm
LAN_LED1
LAN LED Header
2x5 header, 2.54mm
BKLT1
LVDS Backlight Control header
WAFER 1x5P, 2.00mm
LPT1
Parallel Port Connector
WAFER 2x13P, 2.0mm
GPIO_HDR1
GPIO 8 bits Connector
WAFER 2x6P, 2.00mm
J_I2C1
I2C Connector
WAFER 1x4P, 2.00mm
J_SMB1
SMBUS Connector
WAFER 1x5P, 2.00mm
SPI_HDR1
SPI Header
2x4 header, 2.54mm
J6
eSPI Header
2x5 header, 2.00mm
J57
KBMS Header
WAFER 1x 6P, 2.54mm
