BCM RX680R - Page 77

RX680R User’s Manual
77
Field Name
PCI Express Configuration
Help
PCI Express Configuration settings
Comment
Press Enter when selected to go into the associated Sub-Menu.
Field Name
SATA Configuration
Help
SATA Device Options Settings
Comment
Press Enter when selected to go into the associated Sub-Menu.
Field Name
USB Configuration
Help
USB Configuration settings
Comment
Press Enter when selected to go into the associated Sub-Menu.
Field Name
HD Audio Configuration
Help
HD Audio Subsystem Configuration settings
Comment
Press Enter when selected to go into the associated Sub-Menu.
Field Name
LVDS Board I225 LAN 1 Controller
Default Value
[Enabled]
Possible Value
Enabled
Disabled
Help
Enable or disable onboard I225 LAN 1.
Field Name
LVDS Board I225 LAN 2 Controller
Default Value
[Enabled]
Possible Value
Enabled
Disabled
Help
Enable or disable onboard I225 LAN 2.
Field Name
Wake On Lan from LAN Device
Default Value
[Enabled]
Possible Value
Enabled
Disabled
Help
Enable or disable WOL from I225 LAN Device.
Field Name
DeepSx Power Policies
Default Value
[Disabled]
Possible Value
Disabled
Enabled in S4-S5
Enabled in S5
Help
configure the DeepSx Mode configuration.
Field Name
State After G3
Default Value
[S5 State]
Possible Value
S0 State
S5 State
Help
Specify what state to go to when power is re-applied after a power failure (G3 state).
Field Name
GPIO Group Control
Default Value
[Disabled]
Possible Value
Disabled
Enabled
Help
GPIO Header Control Enable/Disable.
