BEALE DP500 - MIDI Implementation Chart

A part of Australian history since 1893.
8
6
Function Transmitted Recognized Remarks
Basic Default 1ch 1-16ch
Channel Changed 1-16ch 1-16ch
Mode
Default x 3
Messages x x
Altered *********** x
Note Note 0-127 0-127
Number :true voice ********** 0-127
Velocity
Note on 9nH,V=1-127 9nH,V=1-127
Note off x (9nH,V=0) (9nH,V=0; 8nH,V=0-127)
After key’s x x
Touch Ch’s x x
Pitch Bend x o
Control 0 o o Bank select
Change 1 x o Modulation
5 x o Portamento Time
6 o o Data Entry
7 o o Volume
10 x o Pan
11 x o Expression
64 o o Sustain Pedal
65 x o Portamento ON/OFF
66 o o Sostenuto Pedal
67 o o Soft Pedal
80 x o Reverb Program
81 x o Chorus Program
91 o o Reverb Level
93 o o Chorus Level
120 o o All sound Off
121 x x Reset All Controllers
123 o o All notes off
Program o o
Change :true ******** 0-127
System Exclusive x o
System :SongPosition
x x
Common
:Song Select x x
:Tune x x
System :clock o x
Real Time :Commands x*1 x
Aux :LOCAL ON/OFF x x
Messages :
:Active sense x o
: Reset x x
Notes: *1 When the accompaniment is started, an FAH message is transmitted.
When accompaniment has stopped, an FCH message is transmitted.
MiDi iMPleMentation Chart
