3.5.4. Frequency Storage Functions
Start store function by pressing:
• "STO" key in "Standard Mode", "Direct Tune Mode" and "SCAN Mode".
During this procedure, the display looks similar to the channel mode with one difference
that "STO" appears on the left side of the display.
3.5.4.1. Store
The transceiver provides two databases:
• User channels database - provides 99 channels CH01 to CH99 to store frequencies with
the possibility to apply a customized label (identifier) with max. 10 alphanumeric
characters.
• Last channels database - automatically stores 9 last used frequencies with customized
identifier if applied, easy to recall as LAST 1 to LAST 9.
Any frequency can be assigned to any channel within the range from 118.000...136.9916 MHz by
simply pressing the "STO" button. All 99 channels are editable. By entering the storage procedure, the
device will first propose the next free channel for storing the active frequency. The label "FREE"
appears together with the channel number, if the selected channel is vacant. A selected channel with
an already stored frequency, has the label "USED".
If the same frequency is stored a second time, then the existing data (frequency, label/identifier data)
is offered to store. If the frequency has no label attached, ten underscore digits allows to insert a label.
The cursor automatically appears on the first position.
The data can be stored to:
• Next free channel (offered from system).
• A selected free channel.
• A selected used channel (the existing data will be replaced).
STO
CH
FREE
09
125.875
STO
09
CH
USED
125.875
STO
_ _ _ _ _ _ _ _ _ _
125.875
STO
TWR EDSB _ _
125.875
Label (Identifier) Data:
By turning the "ROTARY ENCODER" characters can be selected. Selection works in both directions
(example: A...Z0...9—/blankA" by turning clockwise and vice versa by turning
counter clockwise).
Each "short press" on the "ROTARY ENCODER", the cursor is passed to the next position. A short
press of the "STO" key stores the label a long press of the "STO" key clears the currently edited label.
After storing the transceiver returns back to the previous frequency selection mode.
If no action occurs in label editing mode within 7 seconds, the transceiver returns to the previous
frequency selection mode without storing the frequency and label information.
Stored frequencies are recallable in Channel Mode (see "Channel Mode" page 104).
