Installation
Limitations
DV14307.03 Issue 04 March 2016 Transceiver Family 620X 33
2. Installation
This manual must be available close to the device during the performance of all tasks.
The installation of the transceiver depends on the type of aircraft and its equipment. Therefore, this
section only provides general information.
Careful planning should be applied to achieve the desired performance and reliability from the product.
Any deviations from the installation instructions prescribed in this document shall be accomplished in
accordance with the requirements set forth in FAA AC 43 (Federal Aviation Administration, Advisory
Circular).
In this chapter you can read about:
2.1. Limitations ................................................................................................................................... 33
2.2. Packaging, Transport, Storage ................................................................................................... 33
2.3. Device Assignment ..................................................................................................................... 34
2.4. Mechanical Installation ................................................................................................................ 36
2.5. Electrical Interface ....................................................................................................................... 44
2.6. Installation and Configuration ..................................................................................................... 52
2.7. Antenna Installation ..................................................................................................................... 53
2.8. Configuration Setup .................................................................................................................... 53
2.9. Factory Default Settings .............................................................................................................. 68
2.10. Wiring Diagrams and Settings..................................................................................................... 70
2.11. Predesigned Cable Harness ....................................................................................................... 89
2.12. Retrofitting AR4201 with AR6201 ............................................................................................... 89
2.13. Post Installation Tests ................................................................................................................. 92
2.14. Trouble Shooting ......................................................................................................................... 95
2.15. Continued Airworthiness ............................................................................................................. 96
2.1. Limitations
620X design allows installation in cockpit environment of general aviation aircraft including helicopters.
Following limitations apply for the installation of the unit:
• Installations must be in accordance with appropriate EASA or FAA approved guidelines.
The personnel installing this device must ensure that the aircraft installation conditions are
within the ETSO/TSO standards applicable for the specific type or class of aircraft,
• The 620X transceiver must be connecting to a VHF antenna in order to satisfy
FAA TSO-C169a.
• The conditions and tests for ETSO/TSO approval of this article are minimum performance
standards.
• The equipment is not qualified for installation in areas where fluid contamination is quite
likely.
Changes or modifications made to this equipment not expressly
approved in written form by Becker may void the authorization to
operate this equipment.
2.2. Packaging, Transport, Storage
Visually inspect the package contents for signs of transport damage.
Packaging Material and Transport
The packaging material is inflammable, if it is disposed of improperly
by burning, lethal fumes may develop.
The packaging material can be kept and reused in the case of a return shipment. Improper or faulty
packaging may lead to transport damages.
