Becker AR620X - Technical Data

General Description
Technical Data
DV14307.03 Issue 04 March 2016 Transceiver Family 620X 21
1.7. Technical Data
620X
Variants
Nominal supply voltage range
11.0…30.3 V
all variants
Extended supply voltage range
10.25…32.2 V
all variants
Emergency operation
9.0...10.25 V
all variants
Dimming control
0…14 V or 0…28 V
all variants
Frequency range
118.000...136.975 MHz
(-1XX variant)
118.000...136.9916 MHz
(-0XX variant)
Channel spacing
25 kHz
(-1XX variant)
8.33/25 kHz
(-0XX variant)
Number of channels
760
(-1XX variant)
2280 +760
(-0XX variant)
Storage Temperature range
-55...+85 °C
all variants
Operating Temperature range
-20...+55 °C
AR620X-(XXX), RCU6201-(XXX)
-40...+55 °C
RT6201-(XXX)
short-time +70 °C
all variants
Operating Altitude
35 000 ft
Vibration
Category S (Curve M) +
Category U (Curve G)
Typical Power Consumption
AR620X
(X2X)
6 W
AR620X
(X1X)
10 W
RT6201
(X2X)
6 W
RT6201
(X1X)
10 W
RCU6201
(XXX)
Power "off" @ 12 VDC
≤ 0.10 mA
≤ 0.10 mA
≤ 0.10 mA
≤ 0.10 mA
≤ 0.10 mA
Power "off" @ 27.5 VDC
≤ 0.10 mA
≤ 0.10 mA
≤ 0.10 mA
≤ 0.10 mA
≤ 0.10 mA
Reception stand-by mode
@ 13.75 VDC,
panel backlight off
≤ 140 mA ≤ 140 mA ≤ 120 mA ≤ 120 mA ≤ 20 mA
Reception stand-by mode
@ 27.5 VDC,
panel backlight off
≤ 80 mA ≤ 80 mA ≤ 80 mA ≤ 80 mA ≤ 20 mA
Transmit mode (in %)
@ 13.75 VDC, VSWR=1:1
1.8 A at 70%
1.5 A at 0%
-
1.8 A at 70%
1.5 A at 0%
- ≤ 0 mA
Transmit mode
@ 27.5 VDC, VSWR=1:1
1.2 A at 70%
1.0 A at 0%
1.4 A at 70%
1.0 A at 0%
1.2 A at 70%
1.0 A at 0%
1.4 A at 70%
1.0 A at 0%
≤ 20 mA
Absolute maximum current
@ 13.75 VDC, VSWR=3:1
≤ 3 A - ≤ 2,9 A - ≤ 20 mA
Absolute maximum current
@ 27.5 VDC, VSWR=3:1
≤ 2 A ≤ 2.5 A ≤ 1.9 A ≤ 2.4 A ≤ 20 mA
