Installation
Predesigned Cable Harness
DV14307.03 Issue 04 March 2016 Transceiver Family 620X 89
2.11. Predesigned Cable Harness
2.11.1. 1K065 for General Aviation
7
6
5
4
3
2
1
Figure 2-30: Cable harness 1K065
Connector
1
Dsub connector (to P1 unit connector)
2
Connector for PTT switch (see 7)
3
Power supply lines
4
2x Microphone, jack socket PJ68
5
2x Phone, jack socket PJ55
6
Audio input, jack socket 3.5 mm
7
PTT switch
Order code see: "Accessories", page 30.
2.11.2. 1K062 (Open Cable Ends)
The cable harness 1K062 has open cable ends, the basic construction is like type 1K065.
2.12. Retrofitting AR4201 with AR6201
In most cases, a retrofit of the AR4201 with an AR6201 will not cause any problems.
However, in a few cases differences may occur due to pin incompatibility.
Connecting the AR6201 to an AR4201 wiring will NOT damage the AR6201 or the aircraft installation.
