Becker AR620X - Twin Seat Motor Glider; Configuration Setup

Installation
Wiring Diagrams and Settings
DV14307.03 Issue 04 March 2016 Transceiver Family 620X 73
2.10.2. Twin Seat Motor Glider
2.10.2.1. Configuration Setup
Sub-Menu
Function: / Selection
"SPKR VOLUME
SOURCE
BOTH
"CONFIGURATION"
"SWAP MIKE IC" : Disabled
"IN/OUT CFG1"
(/MIKE_SW open):
"MICROPHONE 1" : STD_1 MIKE
"MICROPHONE 2" : NONE
"BOTH MIKES" : Enabled
"HEADPHONE 1" : Enabled
"SPEAKER" : Disabled
"IN/OUT CFG2"
(/MIKE_SW closed):
"MICROPHONE 1" : NONE
"MICROPHONE 2" : DYN_MIKE
"BOTH MIKES" : Enabled
"HEADPHONE 1" : Enabled
"SPEAKER" : Enabled
Remarks
The external switch (connected to pin J1-24 /MIKE_SW) has the
following functions:
Open:
• Standard microphone is selected.
• Speaker is disabled.
• Intercom via VOX is possible.
Closed:
• Dynamic microphone is selected.
• Speaker is enabled.
• No Intercom via VOX is possible.
• Permanent speaker sign is visible on LCD screen.
