Beckman Coulter UniCel DxC Synchron 800 User Manual

Modular Chemistry (MC) System
Introduction
UniCel DxC Systems Instructions For Use A13914 System Description
October 2005 Page 2-13
2
Modular Chemistry (MC) System
Introduction
The Modular Chemistry system consists of the following major assemblies:
• Reagent storage area
• Ratio pump
• Sample probe
• Electrolyte injection cup (EIC)
• Flow cell assembly
• Chemistry reaction modules
A detailed description of each component is presented in the following paragraphs.
Reagent Storage Area
The reagent containers used to supply the modular chemistries are located behind the
left front door of the system. The only exception is the CO
2
alkaline buffer which is
located on the ISE module.
Figure 2.6 Modular Chemistry Reagent Storage Area
1. Bar code reader (hand held)
2. Reagent storage area
A015906P.EPS
1
2
