AeroNav 900/880 Series Pilot’s Guide
89000039-010
Rev 1 May 2019 SVS Subsystem 2-17
The active runway in the FMS flight plan is highlighted with a
magenta outline drawing the airfield identifier flag is “planted” at
the runway threshold, if known, or airport reference point if not.
SynVis Runway Depiction
