BENNING IT 130 Measurements
- 24 -
4.2 Function selector switch
The function selector switch is intended for selecting the
 test and measuring functions
 "AUTO" mode
 "SETTINGS" mode
Key functions after having selected the test / measuring function:
UP / DOWN
Selects the sub-function of the adjusted test / measuring function
(only for rotary switch positions R
LOW
, Z
I
, Z
S
, FI/RCD)
TAB
Selects the parameters and limiting values
TEST
Start of measurement
MEM
Storage / recall of the measuring results
ESC
Back / cancel
Key functions in the Parameters field:
UP / DOWN
Modifies the selected parameter
TAB
Selects the next parameter
MEM
Storage / recall of the measuring results
Parameters and limiting values for evaluating the measuring results:
WITHOUT
No parameters / limiting values, indication: _ _ _.
Parameter,
limiting value
ON
Measuring results – will be marked as "PASS" / "FAIL" according to
the parameters and limiting values set
Please find further information on how to use the test / measuring functions of the installation
tester in chapter 5. Measurements.
4.3 "AUTO" mode
Turn the function selector switch to the "AUTO" mode to select the test / measuring functions
carried out by means of the "Commander" test probe or the optional "Commander" test plug for
shock-proof sockets (044149).
Select the test / measuring function by means of the keys of the "Commander".
Please find a detailed description of the "Commander" test probe and the optional
"Commander" test plug for shock-proof sockets (044149) in Appendix C.
