Benning IT 130 - 8.8 TRMS current (AC; DC) via current clamp adapter

BENNING IT 130 Technical data
- 78 -
8.8 TRMS current (AC / DC) via current clamp adapter
Measuring input C1 of the installation tester:
Maximum voltage ......................................................................... 3 V
Frequency .................................................................................... 0 Hz, 40 Hz ÷ 500 Hz
AC current clamp adapter BENNING CC 1 (044037)
Range = 400 A
Output signal ................................................................................ 1 mV AC per 1 A AC
Frequency .................................................................................... 50 Hz ÷ 60 Hz
Measuring range (A) Resolution (A) Accuracy*
0.00 ÷ 0.99
0.01 indicative
1.00 ÷ 19.99
0.01
±(3 % of the measured value + 0.5 A)
20.0 ÷ 349.9
0.1
±(3 % of the measured value + 0.5 A)
350.0 ÷ 399.9
0.1
±(5 % of the measured value + 1 A)
AC current clamp adapter BENNING CC 2 (044110)
Range = 20 A
Output signal ................................................................................ 1 mA AC per 1 A AC
Frequency .................................................................................... 48 Hz ÷ 65 Hz
Measuring range (A) Resolution (A) Accuracy*
0.0 m ÷ 99.9 m
0.1 m indicative
100 m ÷ 499 m
1 m
indicative
500 m ÷ 999 m
1 m
±(5 % of the measured value + 0.5 A)
1.00 ÷ 19.99
0.01
±(5 % of the measured value + 0.5 A)
AC / DC current clamp adapter BENNING CC 3 (044038)
Range = 40 A
Output signal ................................................................................ 10 mV AC/DC per 1 A AC/DC
Frequency .................................................................................... 0 Hz, 40 Hz ÷ 400 Hz
Measuring range (A) Resolution (A) Accuracy*
0.00 ÷ 1.99
0.01
±(3 % of the measured value + 0.2 A)
2.00 ÷ 19.99
0.01
±(3 % of the measured value + 0.3 A)
20.0 ÷ 39.9
0.1
±(3 % of the measured value + 0.5 A)
Range = 300 A
Output signal ................................................................................ 1 mV AC/DC per 1 A AC/DC
Measuring range (A) Resolution (A) Accuracy*
0.00 ÷ 19.99
0.01
20.0 ÷ 39.9
0.1
indicative
40.0 ÷ 199.9
0.1
± (4 % of the measured value + 1 A)
200.0 ÷ 299.9
0.1
± (4 % of the measured value + 2 A)
* The specified accuracy shall apply to the BENNING IT 130 installation tester and the BENNING
current clamp adapters used.
