8 Technical data
8.1 Insulating resistance
Insulating resistance (nominal voltages of 50 V
DC
, 100 V
DC
and 250 V
DC
)
Measuring range according to EN 61557-2: 0.15 MΩ ÷ 199.9 MΩ
Measuring range (MΩ
ΩΩ
Ω) Resolution (MΩ
ΩΩ
Ω)
Accuracy
0.00 ÷ 19.99
0.01
±(5 % of the measured value + 3 digits)
20.0 ÷ 99.9 ±(10 % of the measured value)
100.0 ÷ 199.9
0.1
±(20 % of the measured value)
Insulating resistance (nominal voltages of 500 V
DC
and 1000 V
DC
)
Measuring range according to EN 61557-2: 0.15 MΩ ÷ 999 MΩ
Measuring range (MΩ
ΩΩ
Ω) Resolution (MΩ
ΩΩ
Ω)
Accuracy
0.00 ÷ 19.99
0.01
±(5 % of the measured value + 3 digits)
20.0 ÷ 199.9
0.1
±(5 % of the measured value)
200 ÷ 999
1
±(10 % of the measured value)
Voltage
Measuring range (V) Resolution (V) Accuracy
0 ÷ 1200
1
±(3 % of the measured value + 3 digits)
Nominal voltages ....................................50 V
DC
, 100 V
DC
, 250 V
DC
, 500 V
DC
, 1000 V
DC
Open-circuit voltage................................-0 % / +20 % of the nominal voltage
Measuring current...................................min. 1 mA at R
N
=U
N
×1 kΩ/V
Short-circuit current ............................... max. 3 mA
Number of possible tests ....................... > 1200, with fully charged battery / storage battery
Automatic discharge after test.
The accuracy specified shall apply for the use of the three-wire test cable and shall apply up to
100 MΩ for the use of the "Commander" test probe.
The accuracy specified shall apply up to 100 MΩ for a relative air humidity > 85 %.
If the installation tester gets wet, the results might be affected. In this case, it is recommended to let
the installation tester and its accessories dry for at least 24 hours.
The maximum error under operating conditions corresponds to the maximum error under reference
conditions ± 5 % of the measured value.
