Benning IT 130 - 6.2 Saving measuring results

BENNING IT 130 Measurements
- 63 -
6.2 Saving measuring results
After measurement, the measuring results and the corresponding parameters can be saved
( icon appears on the LC display). Press the "MEM" key to enter the memory menu.
Figure 6.2: Memory menu
FREE: 96.3%
Free memory capacity for saving measuring results
Keys used in the installation structure field:
TAB
Selects the storage location (object / block / fuse / measuring point)
UP / DOWN
Selects the no. of the selected storage location (1 to 199)
MEM
Saves the measuring results to the selected storage location
ESC / TEST /
function selector switch
Back / cancel without saving
Notes:
 The installation tester automatically suggests the last selected storage location for
saving a new measuring result.
 If you want to save the measuring result to the same storage location as the previous
one, press the "MEM" key twice.
