BENNING IT 130 Measurements
- 62 -
Measuring result field
Type of measurement stored in the selected storage location
No. of the selected measurement / number of all
measurements for each storage location
Example of a typical installation structure in the BENNING IT 130 installation tester:
[OBJ] OBJECT 001
[BLO] BLOCK 001
[FUS] FUSE 001
[CON] MEASURING POINT 001
No.: 1/3
R ISO
Example of a customer-specific installation structure in the BENNING IT 130 installation
tester:
[OBJ] Customer Meyer
[BLO] Distributor of ground floor
[FUS] F1 kitchen
[CON] Socket 1
No.: 1/3
R ISO
Note:
The customer-specific installation structure has been created by means of the BENNING PC-
Win IT 130 logging software and then downloaded to the BENNING IT 130 installation tester.
Once created, installation structures can be stored in the BENNING PC-Win IT 130 logging
software and transmitted once again to the installation tester for periodic testing.
