BENNING IT 130 Measurements
- 55 -
Testing the protective conductor connection (PE)
 Select the Z
I
(L-N/L) [English: Z
LINE
], Z
S
(L-PE) [English: Z
LOOP
] or FI/RCD function by
means of the function selector switch.
 Connect the test cables to the test object (see figure 5.36 and 5.37).
 Touch the silver contact electrode of the "TEST" key for at least two seconds.
 If phase voltage is connected to the PE connection, the warning is shown on the
LC display of the installation tester and the buzzer sounds. Further measurements in
the Zloop (L-PE))and RCD functions are blocked.
Warning:
 If the phase voltage is detected at the protective conductor connection (PE), immediately
stop all measurements and make sure that the fault will be eliminated.
Notes:
 The protective conductor connection can only be tested in the Z
I
(L-N/L) [English: Z
LINE
],
Z
S
(L-PE) [English Z
LOOP
] or FI/RCD positions of the function selector switch.
 A phase voltage at the protective conductor will not be detected, if the operator's body is
completely insulated from the floor or the walls!
 See Appendix C "Commander".
