The machine is controlled from the operator's seat (2). A safety belt (3)
serves to protect the operator. The operator's seat is heated and equipped
with air suspension. There are switches (5) and a joystick (8) on the joystick
console (6) for additional control of machine functions.
The air flow of the cab heater can be directed using the ventilation nozzles
(1).
In case of an emergency, there are two fire extinguishers (4) and an emer‐
gency hammer (9) in the cab.
Further information about the assignment/function of the switches and the
joystick (→ 8.2).
The number and location of the switches on the
rear
control station may
vary depending on the equipment of the machine.
50-020-1011-900_EN
1.0 - © 2/15/2017
127
5 Structure and function
5.2 Technical description of the basic machine (series production equipment)
