Allow the machine to warm up.
►
Remove the screws (2) and open the hydraulic tank (1) maintenance
flap.
►
Using the fill level/thermometer display (1), read off the fill level for the
hydraulic fluid after a few minutes operating time.
The fill level is correct when the minimum (4) is not fallen below when
the working cylinders are fully extended, and the maximum (2) is not
exceeded when the working cylinders are fully retracted.
►
If necessary, have the hydraulic fluid level corrected, see Maintenance/
repair instructions (→ part 2 of the documentation).
Fig. 9.10
Fig. 9.11
50-020-1011-900_EN
1.0 - © 2/15/2017
252
9 Daily maintenance work
9.3 Maintenance work to be carried out
