DANGER! Risk of crushing!
A risk of accident is posed due
to crushing if persons get under
the load being brought down if
the bodies are being lowered
manually.
n Make sure that no persons
are in the danger area
during manual lowering of
the bodies.
►
Actuate the trough rotating valve (2)
on the hexagon (3).
To actuate, use a ring wrench/open-
end wrench (9 mm) to turn and hold
the hexagon.
The round tipping trough can now be
turned manually.
►
Align the round tipping trough man‐
ually via the swivel lock (5).
►
Set the trough rotating valve in the
neutral position.
Fig. 10.
50-020-1011-900_EN
1.0 - © 2/15/2017
268
10 Malfunctions and troubleshooting
10.2 Malfunctions
