Operate the trough tilting valve (1) on the hexagon (4).
To actuate, use a ring wrench/open-end wrench (9 mm) to turn the hex‐
agon.
The round tipping trough lowers under its own weight. The procedure
can take a few minutes.
When lowering, make sure that the round tipping trough engages in the
swivel lock. Align the round tipping trough again if necessary.
50-020-1011-900_EN
1.0 - © 2/15/2017
269
10 Malfunctions and troubleshooting
10.2 Malfunctions
