Bernina 830LE - Inserting the Bobbin; Removing the Bobbin

16
Preparation
Removing / Inserting the Bobbin
Removing the Bobbin
open bobbin cover, the hook system swings to the front ►
push the latch in the center of the bobbin to the left, the ►
bobbin pops out and can be removed
Inserting the Bobbin
with bobbin markings facing the front, place the bobbin ►
into the hook and push until it clicks into place
Threading Lower Thread
pull the thread to the right into slit ► A, then left under the
spring
pull thread over thread cutter ► B and cut
close the bobbin cover slowly, the hook swings back to
►
the rear
A
B
Only remove the bobbin if the hook is at
the end position.
O
n
th
e
The bobbin thread does not have to be
brought up as the loose end is just the right
length to start sewing.
T
br
le
Check the threading path
After threading the hook, hold the mirror under the
swung-out hook unit as shown in the pictures below.
Position of bobbin thread when threaded for sewing ►
