13.4.9 Mounting Brackets for Rod Detectors
D
≈ h
l1 l2 s
ID-No.
for single
brackets
ID-No. for one
set (2 ea.)
brackets
Qty. Use
65 41,5 85 105 1,5 05675 1
85 52 100 122 2 05678
24840
1
rod detector
without water cooling
80 48 85 80 48 05677 1
85 52 100 122 2 05678
24841
1
rod detector
with water cooling
verzinkt
